Feed Crushing and Mixing Machine Poultry animal Feed Crushing and Mixing Machine
This machine is suitable for feed processing such as small feed factories, large and medium farms (chicken farms, pig farms, cattle farms). This machine is a new type of energy-saving feed crushing unit designed by our company's engineers who visite
This machine is suitable for feed processing such as small feed factories, large and medium farms
(chicken farms, pig farms, cattle farms). This machine is a new type of energy-saving feed
crushing unit designed by our company's engineers who visited a large number of farms,
combined with the characteristics of current feed machinery and high labor costs.
The equipment has a large exhaust volume and is self-priming. There are four types of
500, 1000, 1500, 2000, with an output of 1-4 tons per hour, and a small area,
which is suitable for the production of full-price materials.
Features of vertical feed mixer: 1. Short crushing time and high efficiency.
2. The machine has no dust and low noise, which reduces the occupational diseases of the operator.
3. It saves the motor which is especially easy to burn, and it is troublesome and costly to replace
the motor back and forth, which affects the normal use efficiency.
4. Compared with similar products, it can save energy by about one-third.
|
Model |
AWSL-500 |
AWSL-1000 |
AWSL-1500 |
AWSL-2000 |
|
structure type |
Vertical. Single helix |
Vertical. Single helix |
Vertical. Single helix |
Vertical. Single helix |
|
Size(mm) |
1350*1050*2350 |
1370*1240*2700 |
1600*1600*2850 |
1800*1800*2850 |
|
Mixing shaft length(mm) |
2250 |
2630 |
2800 |
2800 |
|
Structural quality (kg) |
130 |
150 |
240 |
330 |
|
Power(kw) |
3 |
3 |
4 |
5.5 |
|
Number of mixing shafts (root) |
1 |
1 |
1 |
1 |
|
Effective volume |
1.36 |
2.18 |
4.03 |
5.08 |
|
Spindle speed(r/min) |
400 |
400 |
400 |
400 |
|
Batch(kg) |
500 |
1000 |
1500 |
2000 |
|
Mixing time (min) |
15 |
15 |
15 |
15 |
