Products Detail

Automatic onion skin removed peeling production line, equipment for processing and removing onion skin shell

Peel off the onion root cutting machine mainly consists of a root, hoist, peeling machines, conveyors and other equipment, the assembly-line device to achieve a small removal rate, peeling rate, over the onion with the device processors. The onion r

11


Peel off the onion root cutting machine mainly consists of a root, hoist, peeling machines, conveyors

and other equipment, the assembly-line device to achieve a small removal rate, peeling rate, over the

onion with the device processors. The onion root cutter is a streamlined operation, which can work

continuously with onion peeling machine, cutting machine, washing machine, air dryer, frying line and

 other equipment, or it can be used alone. The machine is conveyed to the cutting device through the

 stainless steel mesh, and the ends of the lead and the root are cut and then transported to the next

process. The cut root size can be adjusted freely. At the same time, it is equipped with a frequency

conversion speed control function, which can be adjusted freely according to the output size. Finished

 onion crossings are neat, replacing a lot of manual labor.

55


Features of onion peeling machine:

The onion peeling machine adopts the pneumatic principle, the peeling process does not go through

the friction of the blade and the hardness, and it is fully automatic and digitally controlled.

The peeled onion is not easy to be damaged.

 After peeling, the surface with onion is smooth. This equipment has the characteristics of practicality,

 power saving, high production efficiency, easy maintenance and cleaning, and low failure rate.

The pneumatic onion peeling machine is equipped with an automatic feeding device to automatically

 separate onion and onion skin.

This equipment is made of stainless steel, not easy to rust, not easy to corrode, and can work for a long time.

33

onion peeling machine:

size

 2150*1150*2000mm

Voltage

 220V/60HZ

Air source

 ≥1.0MPa

Power

1.52Kw

capability

2t/h (onion diameter 60-100mm)

Weight

 440kg

Onion root cutter:

size

2650*1400*1400mm

Voltage

220V/60HZ

power

2.22KW

capability

2t/h

 Weight

380kg

44
